Monitor
Screen Size 6.8 inches (diagonal) wide
Gesture Touch Control Yes
Panel Type WVGA Capacitive
Key Illumination Colour Variable
Dimmer Yes
Customizable GUI Yes
Multilingual Display Yes, (English, Spanish, French)
Wallpaper Capture Yes
Viewing Angle Adjustment Yes (0 - 20 degree, default : 0 degree)
Radio Tuner
Radio Data Broadcast System (RBDS) Yes
FM Frequency Range 87.9-107.9MHz
AM Frequency Range 530-1,700kHz
Preset Stations 20(FM:15ch, AM:5ch)
SiriusXM Ready Yes
Media Playback
MP3 Compatible with Tag USB
WMA Compatible with Tag USB
WAV Compatible with Tag USB
AAC Compatible with Tag USB
FLAC Compatible with Tag USB
MPEG-1 / MPEG-2 Compatible USB
MPEG-4 Compatible USB
WMV Compatible USB
H.264 Compatible USB
MKV Compatible USB
USB
USB Port(s) x 1
Position Rear
USB Standard High Speed
Drive Change Mode for Mass Storage Class Yes
* Selectable from internal/external memory
1.5A Max. Power Supply Current Yes
Bluetooth®
Built-In Bluetooth® Yes (Wired-Mic included)
* Available functions depend on mobile phone.
Audio Codec AAC / SBC
Auto Pairing for iPhone / Android Yes (Android only)
2 Phones Full-Time Connection Yes
Voice Dialing_ Yes
* Voice recognition compatible mobile phone required
Hands Free Call (HFP) HFP1.8 Wideband Speech
Advanced Audio Distribution Profile (A2DP) yes
5 BT-Audio Connection [JVC Streaming DJ] Yes
Audio/Video Remote Control Profile (AVRCP) Yes
Phone Book Access Profile (PBAP) Yes
Alphabetical Search for Phone Book Yes
Android Control
Android Auto Yes (via USB)
*To use Android Auto on your car display, youll need an Android phone running Android 6 or higher, an active data plan, and the Android Auto app. The service may not be available in certain countries.
Mirroring for Android Yes
Wired mirroring Yes, via USB
＊Need mirroring App
Android Music Playback Yes (via Bluetooth(R))
iPod/iPhone Control
CarPlay Yes (via USB)
*Supported on iPhone XR, iPhone XS, iPhone XS Max, iPhone 11, iPhone 11 Pro, iPhone 11 Pro Max, iPhone 12, iPhone 12 mini, iPhone 12 Pro, iPhone 12 Pro Max, iPhone 13, iPhone 13 mini, iPhone 13 Pro, iPhone 13 Pro Max, iPhone SE (2nd generation), and Apple Watch Series 5 or later. The service may not be available in certain countries.
iPhone Music Playback Yes (via USB (CarPlay) or Bluetooth(AVRCP))
App(s)
JVC Remote S Control App Yes
App Store (Apple) https://apps.apple.com/us/app/jvc-remote-s/id1375474494
Google Play (Android) https://play.google.com/store/apps/details?id=com.jvckenwood.jvcremotes
Audio
Maximum Power Output (Front & Rear) 50Wx4
Full Bandwidth Power (at less than 1%THD) 22W x 4 (Full Bandwidth Power, at less than 1% THD)
Preset EQ Yes (8Preset + 4user)
Volume Link EQ Yes
3-Way X'over Yes
High-Pass Filter/Low-Pass Filter Yes/Yes
Time Alignment Yes
Space Enhancement Yes
Sound Response Yes
Sound Lift Yes
Digital Track Expander Yes
Bass Boost (Hyper Bass System) Yes
Bass Boost (Hyper Bass System) Yes
Inputs and Outputs
Pre-Out Terminals 3 Pairs (Front + Rear + Subwoofer)
Pre-Out Terminals 3 Pairs (Front + Rear + Subwoofer)
Pre-Output Level 4.0V / 10k ohms
AV Input mini jack (AV-IN or Camera-IN switchable) x 1
Video Out RCA x 1
Rear view camera Input Yes
Front view camera Input Yes
General
Back Up Memory Yes
iDatalink Maestro Ready Yes
Wireless Remote Control Ready (RM-RK258 required)
Wired Steering Remote Control Ready Yes
Short Chassis Yes (2-15/16inch, 75mm)
