Specifications
Nominal Diameter 10" / 254mm
Nominal Impedance 4 ohms
RMS Power Handling 300W
MAX Power Handling 600W
Sensitivity (1w/1m) 89dB
Frequency Response 35-250Hz
Recommended Low Pass Crossover 100Hz
Body / Features
UV Compliant Yes, 100% Stable
Marine Grade Type IP65
RGB LED Yes, RGB integrated
Grill Type Injection Molded Composite with 316 Stainless Steel mesh
Sold as Single Yes
Woofer Specifications
Voice Coil Diameter 2" / 50.8mm
Voice Coil Former Material Glass fiber
Winding Material CCAW
Cone Material Injection Molded Polypropylene + UV Compliant
Surround Material Butyl (Rubber)
Basket Material High Temp Injection Molded Composite with UV Protection coating
Magnet Material Ferrite
Magnet Weight 72 oz
Speaker Measurement
Overall Diameter 10.76" / 273.3mm
Overall Depth 6.73" / 171mm
Front Mount Baffle Cutout 8.78" / 223mm
Mounting Depth 5" / 127.5mm
Motor Diameter 5.51" / 140mm
