SPECIFICATIONS
GENERAL
Operating Voltage 10.5 -16 Volts
Current Drain 15 Ampere / (Max)
Low Voltage Warning Alert YES (< 11V)
Waterproof Rating IPX6
UV/Salt Protection YES
Buttons Rubber + RGB Backlit (Blue Color)
DISPLAY
Screen Panel Gorilla Glass with OCA Full Bonding
Type TFT LCD with IPS
Backlight LED
AUDIO
Power Output RMS 4 x 18W @ 4 ohms (14.4v) / 4 x 25W @ 2 ohms (14.4v)
Max 4 x 50W @ 2 ohms (14.4v)
Min Load 2 ohms Stable per Channel
Frequency Response 20Hz to 20KHz
RCA Pre-Out Voltage 4 Volts
Output Impedance 500 ohms
Equalizer 2 Bands (Bass 100Hz ± 10 dB, Treble 10KHz ± 10dB)
Presets YES (S-Bass / Vocal /Powerful / Clarity)
Subwoofer Control Level (-10 to +10)
Audio Zones 2 Zones (Zone 1: Front R+L, Rear R+L / Zone 2: R+L)
Independent Zone Control YES (Level/Tone)
Audio Input L+R RCA (Aux Input)
TUNER
FM Frequency Range 87.5 -107.9 MHz
AM Frequency Range 530 -1710 KHz
Weather Band 162.40 -162.55 MHz
NOAA Weather Band YES Compatible
Tuner Presets 18 FM / 12 AM / 7 WB
Radio Data System YES (AF / TA / NEWS) Selectable
IF 10.7MHz (FM), 450KHz (AM)
Sensitivity 4μV (FM), 36dBuV (AM)
Signal to Noise Ratio >30dB(FM)
Stereo Separation >25dB
CONNECTIVITY
Bluetooth Version 5.0 + EDR
Audio Streaming A2DP
USB Compatibility v2.0
USB Capacity 64 Gb Max
USB Charge Capacity 2.1 Amp
Audio Files Compatibility MP3, WMA
Remote Control Wired 3.5mm Jack Input (Compatible with MXRC)
