SPECIFICATIONS
Nominal Diameter 6x9” / 152.4 x 228.6mm
Nominal Impedance 4 ohms
RMS Power Handling 300w
MAX Power Handling 600w
Sensitivity (1w/1m) 98dB
Frequency Response 80Hz - 12.5KHz
Recommended HI Pass Crossover 100 Hz
Pair or single Single
MOTOR
Voice Coil Diameter 1.5” / 38.6mm
Voice Coil Former Material Glass Fiber
Winding Material CCAW
Cone Material Paper
Bullet Material Aluminum
Surround Material Cloth
Basket Material Aluminum
Basket Color Sandblasted Black
Magnet Material Ferrite + Neodymium
Magnet Weight 30+3 Oz
Displacement Volume 0.62L / 0.0219ft3
MEASUREMENT
Overall Diameter 9.43x6.57” / 240x167mm
Overall Depth 3.7" / 94mm
Front Mount Baffle Cutout 8.74x6” / 222x153mm
Mounting Depth 3.38” / 86mm
Motor Diameter 4.72” / 120mm
