GENERAL SPECIFICATIONS
Nominal Diameter 6X9" / 152x228mm
Nominal Impedance 4 Ohms
RMS Power Handling 60W
MAX Power Handling 180W
Sensitivity (1w/1m) 86dB
Frequency Response 35Hz-20KHz
Recommended HI Pass Crossover 50Hz
Number of ways 3
Pair or Single Pair
Grill Included Yes
WOOFER SPECIFICATIONS
Voice Coil Diameter 1" / 25.5mm
Voice Coil Former Material ASV
Winding Material EISV
Cone Material Paper
Surround Material Rubber
Basket Material Steel
Basket Color/Finish Black Matte
Magnet Material Barium Ferrite
Magnet Weight 15.7Oz / 445g
TWEETER SPECIFICATIONS
Nominal Diameter Tw1: 2.3" / 59mm Tw2: 1.1" / 29mm
Voice Coil Diameter Tw1: 0.6" / 17mm Tw2: Peizo
Voice Coil Former Material Tw1: PESV Tw2: N/A
Winding Material Tw1: EISVM Tw2: N/A
Diaphragm Material Tw1: Mylar Tw2: Mylar
Magnet Material Tw1: Barium Ferrite Tw2: N/A
Magnet Weight Tw1: 34g Tw2: N/A
SPEAKERS MEASUREMENT
Overall Diameter 6.4"x9.2" / 163x234mm
Overall Depth 3.85" / 97.8mm
Overall Diameter (With Grill) 7.24"x10.4" / 184x264mm
Overall Depth (With Grill) 4.15" / 105.5mm
Front Mount Baffle Cutout 5.9x8.66" / 150x220mm
Mounting Depth 2.95" / 75mm
Motor Diameter 4.17" / 106mm
Tweeter Protrusion 0.9" / 22.8mm
